Application
Biosensor / Biochip
BioDot’s precision ultra-low-volume dispensing platforms provide the scalability, speed and accuracy manufacturers need to make biosensors and biochips feasible, both economically and functionally. BioDot technologies print reagents precisely, at picoliter volumes and at rapid speeds.
Examples of biosensor applications that use BioDot’s dispensing technology:
- Bioelectronics
- DNA chips, nucleic acid sensors and aptasensors
- Enzyme-based biosensors
- Immunosensors
- Lab-on-a-Chip
- Mobile diagnostics and personal health
- Nanobiosensors, nanomaterials and nanoanalytical systems
- Natural and synthetic receptors (including MIPs)
- Organism and whole cell based biosensors
- Printed biosensors and microfabrication
- Theranostics and implantable sensors
- Microfluidics
Highlight
High Volume Production
Non-contact, high-speed printing systems for high throughput biosensor manufacturing. Systems can be customized to meet your application needs.
- Custom head designs
- Vision fiducial based positioning
- Automated loading (shuttle nests, sheet feed, etc.)
- Environmental control
- Custom processes and integration
Biosensor / Biochip Products
Biosensor / Biochip
System
Dispense Channels
Mode / Process
Substrates
Dispense Area / Capacity
System Control
Dispense Technology
Options
AD1520™ Aspirate Dispense System
1 - 4
Aspirate & Dispense, Direct Dispense / Lines and Dots
Microwell Plates, Custom Devices
185 x 195 mm Area, 2 MTP Nest or 14 Slide Nest
PC Control, LINK2020 Software, Fiducial Recognition, Humidity Control
BioJet, PolyDrop, PolyJet
Dispensers, Anti-Static
.png)
XYZ3210™ Dispense System
1 - 8
Direct Dispense / Lines and Dots
Membranes, Papers, Custom Devices
495 x 265 mm
Motorized X-Y-Z
μAirJet, AirJet, BioJet, FrontLine, PolyDrop
Dispensers, Vision Inspection, Custom Nest
AD3220™ Aspirate Dispense System
1 - 8
Aspirate & Dispense, Direct Dispense / Lines and Dots
Microwell Plates, Custom Devices
420 x 260 mm Area / 8 MTP Nest or 50 Slide Nest
Motorized X-Y-Z, PC-Control, LINK2020 Software, Fiducial Recognition
BioJet, PolyDrop, PolyJet
Dispensers, Nest Type, Anti-Static, Humidity Enclosure
Omnia™
1 - 4
Aspirate & Dispense, Direct Dispense / Lines and Dots
Microwell Plates, Custom Devices
365 x 250 mm Area, 6 / 8 MTP Nest or 27 / 36 Slide Nest
PC Control, LINK2020 Software, Fiducial Recognition, Humidity Control
BioJet, PolyDrop, Rainmaker, Ultra
Dispensers, Nest Type, Anti Static, Plate Heating, Plate Cooling, Custom Options
GlucoDot™ Dispense System
1 - 4
Direct Dispense / Dots
Biosensor Sheets
420 x 260 mm
PC Control, Axys Software, Waste/Wash Station
BioJet
Humidity Control
CDS Conveyor Dispensing Systems
1 - 9
Direct Dispense, Dots onto Devices or Boards
Assembled Devices and Boards
Custom Conveyor Sizes and Pallets
Motorized Y-Z, Conveyor X Motion
BioJet, PolyDrop, PolyJet
Dispensers, Custom Head Design, Custom Pallets, Environmental Enclosure
AD6020™ Aspirate Dispense System
1 - 16
Aspirate & Dispense, Direct Dispense / Lines and Dots
Microwell Plates, Custom Devices
470 x 555 mm Area / 20 MTP Nest, 100 Slide Nest
Motorized X-Y-Z, PC-Control, LINK2020 Software, Fiducial Recognition, Humidity Control
BioJet, PolyDrop, PolyJet, Rainmaker, Ultra
Dispensers, Nest Type, Anti Static, Plate Heating, Plate Cooling, Custom Options
