BioJet™

This proprietary, quantitative, non-contact technology couples the BioJet “Drop-on-Demand” valve with a high-resolution syringe pump. The BioJet meters precise amounts of reagent, incorporating the benefits of non-contact dispensing and the ability to program exact drop volumes.

  • Drop Volumes: 2.0 nL to 2.0 μL
  • Line Volumes: 0.5 - 3.0 μl/cm
  • Drop Sizes: >130 μm
  • Line Widths: 0.25 - 2.55 mm
  • Program Single Drops or Burst of Drops
  • Non-Contact Printing
  • Direct Dispense or Aspirate & Dispense
  • Precision Low Volume Drop Dispensing
  • Scalable from R&D to Production Environments
  • Printing “Step-and-Repeat” and “On-the-Fly” modes

System Availability

Direct Dispense: ZXLITE, XYZ1010, XYZ3060, XYZ3210, RR120, CDS

Aspirate & Dispense: AD150, Omnia, AD3220, Glucodot, AD6020

Cytogenetics: CellWriter S, CellWriter 960

*Typical application ranges. System, Reagent, Materials and Speed Dependent.
  • Custom Head Designs
  • Extended Tubing (Aspirate & Dispense Systems)
  • Tip ID (Aspirate & Dispense Systems)

Custom Head Designs

Optimize throughput with custom head designs. Adjust the spacing between dispensing channels with a custom head. Extended tubing can also be used to keep aspirated fluid below the BioJet valve.
